Production

Electric vertical machine for mechanical washing and drying of flat sheet glass model NEPTUN LV EVO 1642-30P.

This machine is ideal for use in serial and mass production of glass products for various purposes, as well as in furniture production for glass processing (for example, glass facades, doors, partitions, shelves, display cases and other products).

This machine provides high quality end products, easy operation and has a good reputation in the market.

Main technical parameters:

• Maximum sink height = 1600 mm
• Minimum sink dimensions = 450 x 190 mm
• Glass thickness = 3 - 30 mm
• Working speed = 1 - 7 m/min

Three-axis waterjet cutting machine INTERMAC model PRIMUS 322 is a waterjet cutting machine with three axes, with a built-in PC-based control panel and an ultra-high pressure pump (60,000 psi) for working with stone, glass, metal.

Working area:

• Transverse axis X 3210 mm
• Longitudinal axis Y 2000 mm
• Vertical Z axis 250 mm

Semi-automatic sliding warehouse for glass storage "POWERFUL JAMBO".

It allows you significantly to expand the range of glass on the production area and optimize the storage process during its processing.

Sections are moved mechanically or manually along the guide rails, resulting in a passage. All sections of the warehouse are movable.

Main technical parameters:

• Section load capacity is 10 t
• The maximum size of a box with glass is 6000 x 3210 mm
• Number of sections - 15 pcs

CNC automatic cutting table INTERMAC

CNC cutting table with three controlled axes for straight and curved cutting of monolithic glass and laminated glass. It works with various types of low-e glass.

Main technical parameters:

• The maximum size of the loaded glass is 6100 x 3355 mm
• Glass thickness - 3 - 19 mm
• Head positioning accuracy - ± 0.15 mm

CNC machining center.

Processing that is performed by this center:

• Vertical drilling and profile milling
• Execution of sampling and drilling of various shapes and sizes
• Vertical milling and turning
• Sculptural processing
• Cutting and engraving

Maximum:

• Dimensions are 3300 x 1500 mm
• Weight 1300 kg

Basic model “PROFILE”

PROFILE is a numerically controlled vertical edger for flat glass sheets with rectangular and curved profiles. The machine can perform any type of edging and polishing as well as milling and drilling with maximum precision.

Technical characteristics:

• Tilt is 5 degrees
• Max. glass length is 4500 mm
• Max. glass height is 2800 mm
• Min. glass length (rectangular) is 420 mm
• Min. glass height (rectangular) is 270 mm
• Glass thickness is 3 - 30 mm
• Working surface is 535÷545 mm
• Diagonal accuracy up to 1000 mm is ±0.15
• Accuracy for diagonal over 1000 mm % ±0.015% of glass length
• Accuracy for two consecutive drills is ±0.15 mm
• Accuracy of the first drill from the ground edge ±0.15 mm
• Tool holder chuck is ISO 40 with internal water flow
• Drill head diameter and length are 3÷50 mm
• Length of notches during milling is 90 mm

The automatic line is designed for the production of glazed units of a translucent construction for construction purposes from two or more glasses fastened (glued) to each other along the contour using spacers and sealants.

Main technical parameters:

• Maximum size is 2500 x 4000 (with automatic gas filling)
• Minimum size is 300 x 450 mm
• The thickness of the glazed unit is 12-60 mm
• Glass thickness is 3-19 mm
• Roller height is 450 ± 10 mm
• Brushes: 3 pairs (2 pairs for Low-E)
• Types of glass: - ordinary - energy-saving - glass with low-emission coating - noise-proof – laminated glass

Yuntong Horizontal Glass Tempering Furnace (2019)

The tempering furnace is designed for the production of safety glass by heating and abruptly cooling the glass, as a result of which a surface stress is created on the surface of the glass, providing its increased mechanical strength, heat resistance and safety in case of destruction.

Tempered glass characteristics:

• Maximum loading area is 2800 x 5000 mm
• Minimum glass size is 150 x 400 mm
• Glass thickness: - regular float is from 4 to 19 mm, - low-e glass is from 4 to 10 mm
• Types of glass: - Transparent or mass-colored float glass; - Glass with printed silkscreen pattern; - Simple reflective float glass and K-glass; - Low emissivity glass, emissivity up to 0.01

Full color digital printing on glass with ceramic ink is a revolutionary inkjet technology. This technology allows to depict the full range of colors according to the CMYK color model, using the baking method (hardened printing). The machine operates on the principle of an inkjet printer. The images are sent to a printer that reproduces these patterns on glass in detail, creating photorealistic designs for both interiors and exteriors.

Main technical parameters:

• Maximum size is 3700 x 2800 mm
• Printing definition is Max 720 dpi
• Printing is based on the customer's file (PDF, PS, EPS, Tiff, BMP, JPEG, cdw).

The cross-bending tempering furnace is designed for the production of bent safety glass by heating and abruptly cooling the glass, as a result of that surface stress is created on the glass surface, providing its increased mechanical strength, heat resistance and safety in case of destruction.

Technical characteristics of tempered and curved glass:

• Maximum loading area - 1500 x 1000 mm
• Minimum glass size - 400 x 500 mm
• Glass thickness: - from 4 to 10 mm
• Maximum glass size - 1500 x 1000 mm
• Minimum radius: - 4mm-5mm R≥ 600mm (when bent glass arc length is 1000mm, minimum radius is 1000mm); - 6 mm R≥ 700 mm; - 8 mm R≥ 900 mm; - 10 mm R≥ 1200 mm
• Types of glass: - Transparent or tinted float glass; - One-sided painted float glass and glass with a printed silk-screen pattern; - Plain reflective float glass and K-glass

The line for the production of laminated glass (two or more glasses glued together with a special polymer film capable of holding fragments upon impact). As a rule, it is made by pressing when heated. It is used for glazing vehicles (windshields of cars, railway rolling stock, aircraft, ships, etc.), windows and facades of buildings.

Technical characteristics:

• Maximum glass size - 1800 x 3500mm
• Minimum glass size - 300 x 420 mm
• Product thickness - 4-80 mm

Yuntong Glass Tempering Furnace is designed to produce safety glass by heating and quenching the glass, which creates a surface stress on the surface of the glass to improve its mechanical strength, heat resistance and shatter safety.

Tempered glass specifications:

• Maximum loading area - 2100 x 3600 mm
• Minimum glass size - 100 x 350 mm
• Glass thickness: - from 4 to 19 mm
• Types of glass: - Colorless or tinted flat glass; - Glass with printed silkscreen pattern; - Energy-saving reflective glass
